Bar Code Reader 1D-2d-qr approx appls22ws/ usb/ bluetooth/ radiofrequency

appLS22WS

- The APPLS22WS is designed for retail environments that require a high-precision wireless 2D scanning solution. It allows you to efficiently read 1D and 2D barcodes both printed and digital displays, and is able to read corrupt and low-quality codes.

- Easy installation, easy handling and ergonomic design.

- It has reading aviser through LED and beeper light.

- It can be connected both by Radio Frequency at 2.4 GHz and Bluetooth.

- Fully suitable for commercial use, telecommunications, warehouse, logistics, public security system, etc., the appLS22WS is a bar code reader designed to meet your business demands.

- Specifications

- Type: Imager area image.

- Scan mode: 1D/2D Imager

- Scanning speed: 30fps

- Resolution: 640*480

- Depth scanning area: 5-200 mm

- Fire mode: manual or automatic (self-detecting objects)

- Error index: 1/100000

- Input voltage: 5V+5%

- Interface load: USB

- Scan angle: 55° inclination / oblique 55° / 360° rotation

- Wireless connection: RF and Bluetooth

- Battery: 2000 mAh

- Charging time: 5 hours

- Operating time: 12 hours (in continuous mode)

- Operating distance: RF 2.4GHz - 100 m / Bluetooth - 10 m (open field).

- Indication mode: LED and beeper light

- IP protection degree: IP52

- Decoding capacity: 1D bar code such as UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39 (with full ASCII), Codabar (NW7), Code 128 & EAN 128, Code 93, Interleaved 2 of 5 (ITF Addendum)

- 2 of 5, IATA Code, MSI/Plessy, China Postal Code, Code 32 (Italian Pharmacode), RSS-14, RSSLimited, RSS-Expand, etc. / 2D bar code like QR Code, Data Matrix, PDF417, Aztec, Maxicode Dotcode, GS1 DataBar stack, etc.

- Size (L x W x H): 175 x 66 x 94 mm

- Weight: 183g

- Color: Black

- Packaging content

- APPLS22WS

- User manual
